SCHNEIDER ELECTRIC 9001KY3 - Selector Switch
This device is an electromechanical selector switch from the SCHNEIDER ELECTRIC Harmony 9001K series, designed for robust manual control input in industrial environments. It provides discrete signal generation for machine state selection, mode changes, or operational sequencing within control panels. Engineered for heavy-duty applications, it integrates into systems requiring reliable human-machine interface for process and motor control.
Technical Specifications:
- SERIES/FAMILY: Harmony 9001K
- COMPONENT TYPE: Selector Switch Operator
- ELECTRICAL SPECS:
- NOMINAL CONTACT BLOCK RATING: 10A at 600VAC/DC (dependent on attached contact blocks)
- CONTACT BLOCK COMPATIBILITY: Accepts standard Harmony 9001K contact blocks
- MECHANICAL/PHYSICAL:
- OPERATOR TYPE: Maintained Selector Switch
- NUMBER OF POSITIONS: 3 Positions
- OPERATOR COLOR: Yellow
- BEZEL MATERIAL: Chrome-plated metal
- MOUNTING DIAMETER: 30.5 mm
- INTERFACE/CONTROL:
- CONTROL ACTION: Rotary actuation for position selection
- FEEDBACK: Visual position indication
- CONTACT CONFIGURATION: Dependent on attached contact blocks (not included with operator)
- ENVIRONMENTAL/MOUNTING:
- IP RATING: IP66 (when properly installed with appropriate contact blocks and enclosure)
- NEMA RATING: NEMA 1, 2, 3, 3R, 4, 6, 12, 13 (when properly installed)
- MOUNTING STYLE: Panel mount, 30.5mm cutout
- OPERATING TEMPERATURE: -25°C to +70°C
- COMPATIBILITY/APPLICATION:
- TARGET SYSTEMS: Industrial control panels, motor control centers, process automation systems, heavy machinery
- APPLICATIONS: Mode selection, start/stop control, speed selection, manual override functions
