KEYENCE CORP TV4-CP70 - Vision Sensor Controller
The KEYENCE TV4-CP70 is a dedicated vision sensor controller designed for industrial automation applications requiring high-speed image processing and reliable object detection. This unit integrates advanced AI-driven algorithms and traditional rule-based tools to perform precise presence/absence verification, position alignment, and defect inspection. It serves as the central processing unit for the IV2 Series Vision Sensor system, facilitating robust quality control and process optimization in manufacturing environments.
Technical Specifications:
- SERIES/FAMILY: IV2 Series Vision Sensor
- COMPONENT TYPE: Vision Sensor Controller
- ELECTRICAL SPECS:
- NOMINAL VOLTAGE: 24 VDC
- CURRENT CONSUMPTION: 1.0 A to 2.0 A (typical, dependent on connected camera and lighting)
- POWER CONSUMPTION: 24 W to 48 W (typical)
- MECHANICAL/PHYSICAL:
- FORM FACTOR: Compact industrial enclosure
- MOUNTING STYLE: DIN rail mount or screw mount
- INTERFACE/CONTROL:
- COMMUNICATION PROTOCOLS: Ethernet/IP, PROFINET, CC-Link IE Field Basic, RS-232C, Standard Ethernet (for PC connection)
- I/O: Multiple digital inputs (e.g., trigger, program switching), Multiple digital outputs (e.g., judgment results, strobe control)
- FEEDBACK: Image data output, judgment results, statistical data
- CAMERA INTERFACE: Dedicated high-speed interface for IV2 Series Camera Heads
- LIGHTING CONTROL: Integrated strobe control for connected lighting
- ENVIRONMENTAL/MOUNTING:
- IP RATING: IP20
- COOLING METHOD: Natural air cooling
- OPERATING TEMPERATURE: 0 to +50 degrees Celsius
- STORAGE TEMPERATURE: -20 to +60 degrees Celsius
- HUMIDITY: 35 to 85% RH (no condensation)
- COMPATIBILITY/APPLICATION:
- TARGET SYSTEMS: Automated assembly lines, packaging machinery, robotic cells, quality control stations, material handling systems
- COMPATIBLE CAMERAS: KEYENCE IV2 Series Camera Heads
