SCHNEIDER ELECTRIC 31100 - 3-Pole Contactor
This component is an electromechanical 3-pole contactor from the SCHNEIDER ELECTRIC TeSys D series, engineered for reliable switching of three-phase motor loads and resistive circuits. It features a 24V DC control coil for actuation and is designed for integration into industrial control panels, providing robust power circuit management in diverse automation applications.
Technical Specifications:
- SERIES/FAMILY: TeSys D
- COMPONENT TYPE: Contactor
- ELECTRICAL SPECS:
- POLES: 3-Pole
- MAIN CONTACTS: 3 Normally Open (3NO)
- RATED OPERATIONAL CURRENT (AC-3): 9 A at <= 440 V
- RATED OPERATIONAL CURRENT (AC-1): 25 A at <= 440 V
- COIL VOLTAGE: 24 VDC
- RATED OPERATIONAL VOLTAGE: Up to 690 VAC
- MOTOR POWER (AC-3): 4 kW at 400V, 5.5 kW at 440V, 2.2 kW at 220/230V
- MECHANICAL/PHYSICAL:
- AUXILIARY CONTACTS: 1 Normally Open (1NO) + 1 Normally Closed (1NC) (integrated)
- MECHANICAL LIFE: 15 Mcycles
- ELECTRICAL LIFE (AC-3): 1.6 Mcycles
- INTERFACE/CONTROL:
- CONTROL TYPE: Electromechanical coil actuation
- COIL CONSUMPTION (INRUSH): 5.4 W
- COIL CONSUMPTION (HOLD): 5.4 W
- ENVIRONMENTAL/MOUNTING:
- IP RATING: IP20 (front face)
- OPERATING TEMPERATURE: -5 to 60 degrees C
- MOUNTING: DIN rail or screw fixing
- COMPATIBILITY/APPLICATION:
- APPLICATIONS: Motor control, resistive load switching, power distribution, HVAC systems, pumping stations, material handling equipment.
- COMPATIBILITY: Compatible with TeSys D series auxiliary contact blocks, thermal overload relays, and accessories.
