SCHNEIDER ELECTRIC 31130 - Motor Circuit Breaker
The SCHNEIDER ELECTRIC 31130 is a TeSys GV2ME series thermal-magnetic motor circuit breaker, engineered for the protection and control of three-phase AC motors. It integrates robust short-circuit and overload protection functions, ensuring operational reliability and compliance with industrial motor protection standards. This device is suitable for direct motor starting and local manual control within industrial control panels and machinery applications.
Technical Specifications:
- SERIES/FAMILY: TeSys GV2ME
- COMPONENT TYPE: Motor Circuit Breaker, Thermal-Magnetic
- ELECTRICAL SPECS:
- NOMINAL OPERATING VOLTAGE: Up to 690VAC
- THERMAL TRIP ADJUSTMENT RANGE: 2.5 - 4 A
- MAGNETIC TRIP CURRENT: 52 A (approx. 13 x In)
- BREAKING CAPACITY (Icu): 100 kA at 230/240VAC 10 kA at 400/415VAC 3 kA at 690VAC
- NOMINAL MOTOR POWER (3-Phase): 0.75 kW at 220/230/240V 1.5 kW at 380/400/415V 4 kW at 660/690V
- PHASE: Three-phase
- FREQUENCY: 50/60 Hz
- MECHANICAL/PHYSICAL:
- CONTROL TYPE: Rotary Knob (Manual)
- NUMBER OF POLES: 3P
- TERMINALS: Screw clamp terminals
- FORM FACTOR: Compact, modular design
- INTERFACE/CONTROL:
- CONTROL METHOD: Local manual operation
- AUXILIARY CONTACTS: Optional add-on blocks (e.g., GV-AD, GV-AN) for signaling
- ENVIRONMENTAL/MOUNTING:
- IP RATING: IP20 (Terminals), IP40 (Front face)
- COOLING METHOD: Natural convection
- MOUNTING STYLE: 35mm DIN rail
- OPERATING TEMPERATURE: -20 to +60 degrees C
- COMPATIBILITY/APPLICATION:
- TARGET SYSTEMS: Industrial motor control panels, machinery requiring motor protection
- SPECIFIC MACHINE TYPES: Pumps, fans, conveyors, machine tools, and general industrial motor loads.
