SCHNEIDER ELECTRIC 56160 - Modicon M340 Processor Module
This component, identified by the internal code 56160, is a core processor module within the SCHNEIDER ELECTRIC Modicon M340 Programmable Automation Controller (PAC) series. It provides centralized logic execution, data management, and communication capabilities for industrial control systems. Designed for medium-sized applications, it integrates into a modular rack architecture, facilitating control in discrete manufacturing, process automation, and infrastructure management.
Technical Specifications:
- SERIES/FAMILY: Modicon M340
- COMPONENT TYPE: Processor Module (CPU)
- ELECTRICAL SPECS: Power supplied via Modicon M340 backplane typical internal consumption 24VDC, current draw varies by model (e.g., 150-300mA).
- MECHANICAL/PHYSICAL: Rack-mounted module standard M340 form factor for integration into a 19-inch rack or panel-mounted chassis.
- INTERFACE/CONTROL: Integrated Ethernet port supporting Modbus TCP/IP and EtherNet/IP dedicated CANopen master port Modbus serial port via optional communication modules supports up to 1024 discrete I/O and 256 analog I/O points program memory up to 4MB data memory up to 256KB.
- ENVIRONMENTAL/MOUNTING: IP RATING: IP20 COOLING: Natural convection MOUNTING: Rack-mounted within an industrial control cabinet.
- COMPATIBILITY/APPLICATION: Compatible with Modicon M340 I/O modules, communication modules, and power supply units suitable for machine control, process control, building management systems, and water treatment applications.
