SCHNEIDER ELECTRIC AR1MC014 - Reversing Motor Starter
The SCHNEIDER ELECTRIC AR1MC014 is a compact, integrated TeSys AR1 series reversing motor starter designed for direct control and protection of three-phase AC induction motors. This unit combines contactor functionality, thermal overload protection, and short-circuit protection into a single device, facilitating efficient motor control in industrial applications such as conveyor systems, small pumps, and machine tools. It provides electromechanical switching for forward and reverse motor operation.
Technical Specifications:
- SERIES/FAMILY: TeSys AR1
- COMPONENT TYPE: Reversing Motor Starter
- ELECTRICAL SPECS:
- MAIN CIRCUIT VOLTAGE: Up to 690VAC
- MOTOR CURRENT SETTING RANGE: 0.63 - 1.4 A
- CONTROL CIRCUIT VOLTAGE: Configurable (e.g., 24VDC, 110VAC, 230VAC)
- POWER RATING (TYPICAL): 0.37 kW at 400VAC (for 1.4A max current)
- PHASE: 3-Phase
- FREQUENCY: 50/60 Hz
- MECHANICAL/PHYSICAL:
- FUNCTION: Reversing motor control
- PROTECTION: Integrated thermal overload relay, magnetic short-circuit protection
- FORM FACTOR: Compact, modular
- INTERFACE/CONTROL:
- CONTROL TYPE: Electromechanical contactor-based
- AUXILIARY CONTACTS: Typically includes 1 NO + 1 NC (Normally Open + Normally Closed)
- INDICATORS: Mechanical status indication for trip and operational state
- ENVIRONMENTAL/MOUNTING:
- IP RATING: IP20 (device only), IP55/IP65 (when mounted in appropriate enclosure)
- MOUNTING: 35mm DIN rail or screw mounting
- OPERATING TEMPERATURE: -20 to +60 °C
- COMPATIBILITY/APPLICATION:
- APPLICATIONS: Small to medium power AC motor control, conveyor systems, fans, pumps, machine tools, general industrial machinery.
- MOTOR TYPE: Three-phase AC induction motors.
